Humminbird APEX 13 MEGA SI GPS Chartplotter

Clarity has reached a new peak

Welcome to the top. The Humminbird APEX 13 MEGA SI GPS Chartplotter provides the clearest sonar imaging on the sharpest display the water has ever seen on any GPS chartplotter. Industry-leading MEGA Imaging+ and Dual Spectrum CHIRP sonar come standard, with even more performance from a dedicated sonar channel for accessory 2D CHIRP transducers up to 2kW. See it all clearly with a 13.3″ Full-HD touchscreen that provides a customised display of information from advanced network options like NMEA 2000, HDMI In/Out, WiFi and Bluetooth. Add the power of the One-Boat Network to integrate the accuracy of Humminbird GPS charts, unrivalled boat control from Minn Kota, and reach new depths with wireless Cannon downrigger control. The APEX Series is a new kind of MFD that will take you fishing to a new level.

Full-HD Display with Cross Touch interface
APEX delivers eye-popping detail with a 1920H x 1080V display. See the incredible detail of sonar and chart images that will ensure you never miss a thing. Control it all using the touchscreen or the keypad—it’s up to you.

Industry-leading Humminbird sonar
Equipped with MEGA Side Imaging+, MEGA Down Imaging+ and Dual Spectrum CHIRP sonar to keep you on the fish. MEGA Imaging+ provides views up to 250′ under and out to either side of your boat and Dual Spectrum CHIRP shows exceptional 2D sonar with superior target separation and fish clarity.

Humminbird APEX 13 MEGA SI GPS Chartplotter Features:

• Full-HD Display with Cross Touch interface
• Intuitive user interface and sidebar menu provides custom settings - view combinations to make your fishing experience all your own
• Dual Core Processor - Perform any task with speed and ease, thanks to the ultra-responsive interface and upgraded processing power
• MEGA Side Imaging+ - provides views up to 250′ under and out to either side of your boat
• MEGA Down Imaging+
• Dual Spectrum CHIRP sonar - shows exceptional 2D sonar with superior target separation and fish clarity
• Dual sonar ports offer connection with any Humminbird sonar options, as well as a dedicated port for 2D CHIRP transducers up to 2kW
• Integrated transducer ID provides fast and simple installation of Airmar transducers
• Internal GPS and Humminbird Basemap provides a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence
• AutoChart Live: Create real-time maps of your fishing spots. Map depth contours, bottom hardness and vegetation as you drive your boat. Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually-endless AutoChart Live mapping capacity
• One-Boat Network Compatible
• Dual Ethernet Ports: Easily network products without the need for an external network hub, allowing the connection of multiple control heads and Ethernet accessories like Minn Kota i-Pilot Link and Humminbird CHIRP Radar
• HDMI Compatible - Connect and view accessory camera and video sources, as well as output to accessory displays for more viewing and rigging options
• Bluetooth
• Wireless software updates from the Humminbird FishSmart App and display of smart phone notifications on your Humminbird
• NMEA 2000 networking built-in: Connect an accessory NMEA 2000 network to your control head for even more information; from boat performance to weather and water conditions, make sense of it all with NMEA 2000 networking
• Compatible with CZone Contact 6, Contact 6 Plus and digital switching devices
• Built In GPS

Humminbird APEX 13 MEGA SI GPS Chartplotter Specifications:

• Part number: 104651
• Display Size – Diagonal: 13.3″
• Display Pixel Matrix: 1920H x 1080V
• Sonar-Standard: Dual Spectrum CHIRP, MEGA Down Imaging+, MEGA Side Imaging+
• Sonar-Coverage: 20°, 42°, 60°, (2) 86° & (2) 55° @ -10dB
• Sonar-Optional: 50 kHz, 50/Low Airmar CHIRP and SM3000
• CHIRP – Frequencies Supported: Full Mode (28-75 kHz), Narrow Mode (75-155 kHz), Wide Mode (130-250 kHz), Optional Deepwater (28-250 kHz)
• Sonar-Frequencies Supported: 50/83/200/455/800 kHz & 1.2 MHz
• Depth-Sonar: 1,200 ft (standard transducer), 5,000 ft (optional Airmar CHIRP SM3000)
• CHIRP – Imaging-Frequencies Supported: 455 kHz DI+ (435-535 kHz), 455 kHz SI+ (405-505 kHz), 800 kHz DI+ (800-860 kHz), 800 kHz SI+ (780-840 kHz), MEGA DI+ (1100-1200 kHz), MEGA SI+ (1050-1175 kHz)
• Depth-Down Imaging: 125 ft (800 kHz), 250 ft (MEGA), 400 ft (455 kHz)
• Range-Side Imaging (Side-To-Side): 250 ft (800 kHz), 500 ft (MEGA), 800 ft (455 kHz)
• Interface: Touch Screen
• Memory Card Slot: Dual Micro SD
• Compatible With: AIS, AutoPilot, HDMI In/Out, MEGA 360, Minn Kota Built-In MEGA DI, Minn Kota Built-In MEGA SI, Minn Kota i-Pilot Link, Minn Kota Talon/Raptor, Minn Kota US2 Sonar, NMEA 2000, One-Boat Network, Radar
• Power Draw: 3.3 Amps
• Power Input: 10.8-20 VDC
• Power Output Peak-to-Peak: 8000 Watts
• Power Output RMS: 1000 Watts
• Screen Snap Shot: Included
• Sonar Recording: Included
• Mount-Standard: Gimbal
• Mount-Standard Size: 15.6” W x 9.88” H x 4.88” D
• Mount-Optional Size: 15.6” W x 8.98” H x 0.51” D
• Transducer Mount Location: Transom
• GPS Chartplotting: Included
• GPS Trackplotting: Included
• LakeMaster Compatibility: Yes
• Coast Master Compatibility: Yes
• Navionics Gold/HotMaps Compatibility: Yes
• Navionics Platinum + Compatibility: Yes
• Platinum Compatibility: Yes
• Heading Sensor GPS Compatibility: Yes
• Upgradable Software: Yes
• View Preset Keys: Yes
• Custom Digital Readout: Yes
• Custom View Selections: Yes
• Display Colors Grayscale: 16-Bit
• Display Size: 11″ – 15″
• Speed: Included
• Temperature: Built In
• Temperature Alarm: Yes
• Temperature Graph: Yes
• Transducer Included: XM 14 HW MSI T
• HDMI Compatible: Yes
