Accurate depth readings at any speed
The Airmar DT812PV-235-0 Smart Transducer's ceramic element is tilted inside the housing, which compensates for your boat's deadrise. This aims the beam straight toward the bottom resulting in strong bottom echo returns and accurate depth readings at any speed.
Airmar DT812PV-235-0 Smart Transducer Features:
- Broadband 235 kHz Ceramic
- Low-Profile 12° Tilt
- Plastic, with valve
- Enhanced depth performance
- Urethane face provides better sensitivity
- Excellent high-speed performance NMEA 0183 output
- 6 W RMS power
- All models have depth and temperature
- 235kHz eliminates interference with fishfinders
- Retractable insert provides ease of serviceability
- Reverse polarity protection
Airmar DT812PV-235-0 Smart Transducer Specifications:
- Model: DT812PV-235-0
- Maximum Depth Range: 100 m (330’)
- Minimum Depth Range: 0.5 m (1.6’)
- Supply voltage 8.4 to 31.2 VDC
- Supply current 30 mA maximum
- Usable Shaft Length: ~57 mm (2.25”)
- Frequency: 235 kHz
- Beamwidth: 12°
- 6-15 degrees of deadrise
- 10 m (33’) cable length standard
- Maximum cable length 100 m (330’)
- 51 mm (2”) housing
- Blanking plug included
- Accommodates maximum hull thicknesses 54 mm (2 1/8”)
- Accommodates minimum hull thicknesses 6.3 mm (0.25”)
