Enerdrive Fixed Mono Solar Panel 200W 24V

#9172456
Warranty Badge - 5-Years
Hurry! 1 left in stock - Ready to Ship
Calculate Shipping
Australia Wide
includes any items in cart
ONLY $459.00

Seen a lower price? Ask us to beat it

Add Items to Cart

Click on the image above to view full picture

More Views

Details

Details

Your efficient outdoor power source

The Enerdrive Fixed Mono Solar Panel is suited for a wide range of small-scale off grid solar power applications. Perfect to mount on your boat, caravan or camper van, this solar panel provides excellent power source for your electronic devices when you're on the move.

Enerdrive Fixed Mono Solar Panel Features:
  • High efficiency solar cells, Low resistance loss and higher conversion efficiency
  • High Conversion Efficiency - Module efficiency up to 15.67%
  • Positive tolerance of up to -1%+~3% delivers higher output reliability
  • High PID Resistant
  • System output maximised by reducing mismatch losses up to 2% with modules sorted and packaged by amperage
  • Module certified to withstand extreme wind (2400 Pascal) and snow loads (5400 Pascal)
  • Double EL test before and after lamination, highly controls product defects
  • Solar panel classified by current, to improve system performance

Enerdrive Fixed Mono Solar Panel Specifications:
  • Part number: SP-EN200W
  • Max Power Pm: 200W
  • Power Tolerance %: - 1% ~ + 3%
  • Max Power Voltage Vm: 37.30V
  • Max Power Current Im: 5.37A
  • Open Circuit Voltage Voc: 43.7V
  • Short Circuit Current Isc: 6.05A
  • Max System Voltage: 1000VDC
  • Dimensions: 1580 x 808 x 40mm
  • Weight: 15kg
  • Test Conditions: 1000W/m² , AM1.5 , 25°C
  • Certificates: ISO9001:2015
    ISO14001:2015
    ISO45001:2018
    CE;CQC;SGS;IN METRO;DEKRA

Enerdrive Fixed Mono Solar Panel 200W 24V Product Datasheet
