Victron Orion-TR Isolated DC/DC Converter 12V – 12V 18A (220W) Adjustable Output
Victron Orion-TR Isolated DC/DC Converter 12V – 12V 18A (220W) Adjustable Output
Victron Orion-TR Isolated DC/DC Converter 12V – 12V 18A (220W) Adjustable Output
Deliver to:
Auckland 0626,
NZ
Estimated:
$0.00
2-hour Click & Collect:
(order before 3pm, in-stock products only)
Our Auckland Shop
Free
Buy now, pay later & Finance Options
Find Local Store
Report incorrect product information
The item you're looking at is currently unavailable or has limited stock, how about this one instead?
Powerful and reliable
The Victron Orion-TR Isolated DC/DC Converter delivers the power, range and performance Victron converters are known for. This converter features remote on-off operation which eliminates the need for a high current switch in the input wiring. The remote can be operated with a low power switch or by the engine run/stop switch. With an adjustable output voltage, the unit can also be used as a battery charger to power a 12V starter or as an accessory battery in a 24V system.
The Victron Orion-TR Isolated DC/DC Converter is made short circuit proof and can be paralleled to increase output current. It boasts an IP43 protection rating when installed with the crew terminals oriented downwards. Make sure you install a reliable converter, grab the Victron Orion-TR Isolated DC/DC Converter today!
Victron Orion-TR Isolated DC/DC Converter Features:
- Remote on-off operation
- Adjustableoutput voltage
- Short circuit proof
- Can be installed parallel
- IP43 protection when installed with the screw terminals oriented downwards
- Input fuse
Victron Orion-TR Isolated DC/DC Converter Specifications:
- Input voltage range: 8 - 17V
- Under voltage shut down: 7V
- Under voltage restart: 7.5V
- Nominal output voltage: 12.2V
- Output voltage adjust range: 10-15V
- Output voltage tolerance: +/- 0.2V
- Output noise: 2mV rms
- Cont. Output current at nominal output voltage and 40deg C: 18A
- Maximum output current (10 s) at nominal output voltage: 25A
- Short circuit output current: 40A
- Cont. output power at 25deg C: 280W
- Cont. Output power at 40deg C: 220W
- Efficiency: 87 percent
- Off load current: < 80mA
- Galvanic isolation: 200V dc between input, output and case
- Operating temperature range: -20 to +55deg C (derate 3 percent per deg C above 40deg C)
- Humidity: Max. 95 percent non-condensing
- DC connection: Screw terminals
- Maximum cable cross-section: 16 sq. mm AWG6
- Weight: 1.3 kg (3 lb)
- Dimensions (H x W x D): 130 x 186 x 70 mm (5.1 x 7.3 x 2.8 inch)
- Safety standards: EN 60950
- Emission: EN 61000-6-3, EN 55014-1
- Immunity: EN 61000-6-2, EN 61000-6-1, EN 55014-2
- Automotive Directive: ECE R10-5
